HIO-1

Description

The central hub for seamless connectivity. The HIO-1 consolidates signals and data, simplifying wiring while integrating the throttle, display, lighting, and more. Built-in WLAN and Bluetooth enable app connectivity and remote diagnostics, while the CAN-FD bus ensures fast communication with the controller and inverter. Compact and essential, the HIO-1 optimizes efficiency, reliability, and system integration.

Key features

• Powerful 32bit 240Mhz Processor
• "Helius-Coded"® firmware
• Canbus communication
• WLAN & Bluetooth Low Engery BLE connectivity
• Short circuit & overcurrent protection of all outputs
• Dual Hall Sensor Throttle compatiple
• Outputs for head lights, rear lights, indicators and horn
• Brake & Mapping Switch Inputs

HT-1

Description

The HT-1 throttle delivers precise control with a high-quality bearing system for smooth, responsive throttle operation. Dual Hall sensors ensure reliability, while the ergonomic grip is easily replaced, keeping repair costs low. A moisture-sealed housing protects against the elements, while the optimized layout ensures optimal brake lever clearance for seamless integration.

Key features

• Dual high-precise rotation sensor
• Redundant throttle signals
• Rigid aluminium housing
• Kill switch integrated
• Activation button integrated
• Waterproof and dustproof
• Pure natural feeling
• Direct torque control

HI-4000

Description

With a 4000W rating, the HI-4000 boasts an FOC-regulated controller from market leader Accelerated Systems Inc. (ASI), ensuring maximum efficiency, smooth torque delivery, and precise response. The integrated Vehicle Control Unit actively monitors and manages system performance in real time. A DC/DC converter provides stable 12V power for lighting and accessories, while the DC-cut safety regulator prevents unintended power flow, ensuring safe and controlled operation. Encased in a polymer housing with aluminum cooling fins, the inverter efficiently dissipates heat for sustained performance and durability.

Key features

• Rated power: 4000W
• Peak power: 16000W
• Boost power: 21000W
• Weight: 1850 gr.
• Paired VCC and DCC
• Sensor or sensorless motor control
• High efficient and noiselessly
• EMC compliant

HD-351

Description

Designed for landscape-oriented interfaces, the HD-351 is ideal for vehicles requiring wider display formats. Measuring 102 mm wide and 72 mm high, its bright IPS color display (480 × 320 px) delivers clear visuals, while IP66 protection ensures durability for outdoor use. Featuring USB-A charging, CAN-BUS connectivity, and an auto-adjusting light sensor, it integrates seamlessly into Helius drive systems with customizable branding and interface options.

Key features

• High resolution 480x320 px
• 3.5'' Color IPS screen
• Canbus communication
• USB Type-C, 5V 1A output
• IP66 water resistance
• Wider range of input voltages 12V-60V
• Ultra low power consumption
• -20-70°C operating temperature
• Size 101,5 mm x 74,6 mm

HB-36-2140-V

Description

Designed principally for high-performance motorcycles, the HB36-2140 delivers 2140Wh of power in a lightweight 12 kg design. Power delivery is rated to 350A peak current, while the durable aluminum housing ensures efficient heat dissipation. The Helius Battery Management System continuously optimizes performance via CAN bus. Designed for off-road riding, its compact, slim profile integrates easily, and its replaceable, recyclable cells exceed current EU regulations.

Key features

• 36V low voltage system
• 2140wh capacity
• Rated power output: 3000W
• Peak power output: 7000W
• Boost power output: 8500W
• Weight 12kg
• State of the art SOC and SOH calculations
• Galvanic insulated Battery contacts
• Size 393(350) x 160 x 130 mm (LxWxH)

HM-3000-H

Description

A cost-efficient solution for scooter applications, the HM-3000-H delivers smooth acceleration and reliable performance. Designed for 10 to 14-inch wheels, it offers flexibility for various scooter designs. Its compact construction allows easy integration, while a high-efficiency design maximizes range. Built for urban mobility, it ensures low maintenance and long-term durability.

Key features

• Rated power: 3000W
• Peak power: 6000W
• Boost power: 7000W
• Weight: 9,14 kg
• High torque
• Highly dynamic
• Ultra compact
• Integrated position encoder
• Direct drive

HC-36-1500

Description

Engineered for fast, efficient, and safe charging, the HC36-1500 delivers 1500W at 36V, maintaining constant communication with the Helius Battery Management System via CAN bus for optimized charging speed and long-term battery health. Its fully sealed, waterproof housing and front-mounted cooling fan ensure durability and temperature regulation in demanding environments. Fully EU-certified, it operates with a standard 220V outlet, offering convenient and reliable charging across the European market.

Key features

• Waterproof
• Fan with temperature regulation
• Input voltage 220V CEE 7/7, Schuko
• CE
• CAN Bus communication
